Protect Crash Barriers from Corrosion-Tanya Galvanizers

Protect Crash Barriers from Corrosion

Zinc is exploited globally for its uses and for its unique properties. Its predominant usage (50% to 60%) is for corrosion protection, mainly galvanizing. This means having steel coated using metallic zinc. This is to protect the metal from corrosion. It is regarded to be a highly reactive metal and still can support safeguarding steel from corrosion, when this metal in itself is regarded to be vulnerable and requires adequate protection. But with oxygen present in air reacting with zinc surface, creates impermeable and dense zinc oxide coating. Zinc surface is protected from future attack from this physical crash barriers.

Offering maximum protection

An item that is coated in zinc, like the motorway crash barrier, galvanized dustbin or the roadside lighting standard tends to lose quickly its silver shiny appearance to become dull grey, due to zinc oxide coating formation that is regarded to be natural ageing process. Zinc coating’s physical barrier as well as its surface oxide is what said to protect the steel. Interface present between steel and zinc is actually not a single metal directly one upon the other. A reaction is created by the galvanizing process among steel and zinc, where there is form an intermediate iron-zinc compound, which further offers corrosion barrier including an unbreakable bond among steel and zinc. From steel, zinc is said not to peel away, unlike that of paint.

Providing in numerous benefits

If galvanized steel surface gets broken or scratched, then the exposed steel region is sure to corrode, since the physical protective barrier has been lost. But with zinc being more reactive when compared to iron offers further defence, since iron and zinc forms electrolytic cell similar to that of the battery, where iron’s natural reactivity combined with its desire to get converted into rust is covered to favor the reactive zinc material. Hence, zinc is expected to oxidize a bit and the scratch present in zinc coating will be healed by zinc oxide product. Since the zinc coating area is big, when compared to the coating’s break area, zinc actual loss amount to protect the steel is quite small. Therefore, zinc can be termed to be the perfect protector.

To safeguard steel car bodies, zinc coating provides twelve years of assurance against corrosion, which in itself tends to speak in volumes. The point it, irrespective of the type of painting steel has been provided with, it is simply no match for zinc, when protection is concerned. The reason is because paint offers just the physical barrier, but not the much needed secondary defense, if coating gets broken. As a result, once paint surface gets broken, corrosion tends to advance rapidly within the paint left.

Uses of Crash Barries

Two major galvanizing classifications are present, namely, continuous galvanizing and general galvanizing. Zinc could be applied by electrolysis in continuous galvanizing process. But this process is known to be less used for providing protection. Moreover, the method is used for safeguarding bigger structures like bridges. However, the protection offered is considered to be not that good like the individual component galvanized during primary manufacture. This is because, the application and preparation is not well controlled at the construction site.

Related: Different Uses of Crash Barriers

Crash Barrier galvanizing services are offered by the leading providers like Galvanizers to their clients at reasonable rates. Choosing them over their competitors is likely to benefit the business.

Get in touch with us via Email: or
Phone: (0265) 2632517 (O) / +91 8000842648

What Are The Reasons There Could Be Defects In Galvanizing-Tanya Galvanizers

What Are The Reasons There Could Be Defects In Galvanizing?

Some common defects may arise during hot dip galvanizing process. There are several reasons for the causes of such variations and defects to take place.

Galvanized Coatings: Some defects

  • Ungalvanized weld areas: The weld areas may have some coating misses which could be due to welding shag being present on the welds. The fabricator is required to remove the welding slag before it is delivered to the galvanizer.

  • Mottled or dull gray coatings: Thicker galvanized coatings will be generated by reactive steels which are dull when compared to standard coatings. Such coatings tend to have longer life due to their greater thickness. Moreover, their appearance is steel metallurgy’s function, which is beyond the galvanizer’s control.

  • Dark stains present adjacent to welds: Unsealed overlaps may witness preparation chemicals entering them or poor quality welds simply boil from connection during the galvanizing process. This will only cause coating misses and surface contamination during galvanizing. Moreover, anhydrous fluxing salts remaining within the connection are likely to absorb atmospheric moisture, while leaching onto adjacent galvanized surface. Such salt leaching will each eventually the equilibrium. It is necessary to clean wash the affected areas for removing those slight corrosive leachate.

  • Inclusions/Dross Pimples: During galvanizing process, dross is generated as zinc iron crystals or in the form in higher melting point when compared to metal in zinc bath. Galvanized coating experiences trapped dross which gives out that gritty or rough appearance to the coating. Dross inclusion presence in coatings will not be found to be detrimental to performance of the coating, since zinc dross resistance is identical, similar to that of galvanized coating.

  • Ash staining: During the galvanizing process, there is formation of zinc ash, since it is in zinc that the work gets immersed. The ash that is generated gets skimmed off the molten zinc surface before withdrawal of the work from galvanizing bath. At times, ash can be found to be trapped within the inaccessible areas, while sticking to the external part of the coating, when the bath is exited by the work. A light brown or dull surface stain is left by ash after removal. However, the galvanized coating performance is not affected in any manner.

  • White storage staining: Once galvanizing is completed, the items stacked or stored in poorly ventilated, wet conditions will become white bulky zinc hydroxide deposits upon the galvanized coating surface due to atmospheric moisture reaction.

  • General surface irregularities and striations: Lines thicker than adjacent galvanized coating and ridges may appear due to varying zinc reaction with steel surface. This is more due to the stress areas upon the steel surface or probably the welds presence or weld metal that is modified metallurgy into parent metal. It is regarded to be a common phenomenon faced with tube and pipe products. However, coating performance is not affected in any manner.

  • Bare patches: The uncoated areas of the galvanized work surface are because of inadequate pretreatment in pickling, degreasing, pre-fluxing and poor surface preparation. It is necessary to get the areas repaired by making use of recommend repair procedure or regalvanize the item, if defect is found of sufficient size.

  • Puddling, drainage spikes and runs: They are termed to be unavoidable defects in general item hot dip galvanizing process. They are acceptable unless the function assembly of the item is not affected or safety hazard present in service or handling.

The above are stated to be the few of the reasons for defects to appear in galvanizing and amazing solutions to it.
